INDUSTRIAL RUBBER SHEETS
FKM Rubber Sheet
FKM (Fluoroelastomer) Rubber Sheet is a high-performance synthetic rubber engineered to deliver exceptional resistance to high temperatures, aggressive chemicals, fuels, oils, solvents,…
PRODUCT OVERVIEW
Designed around demanding operating requirements
FKM (Fluoroelastomer) Rubber Sheet is a high-performance synthetic rubber engineered to deliver exceptional resistance to high temperatures, aggressive chemicals, fuels, oils, solvents, and harsh industrial environments. It is widely recognised for its outstanding sealing performance, excellent ageing resistance, and superior durability under extreme operating conditions.
FKM Rubber Sheets are commonly used in industries where standard rubber materials cannot withstand severe chemical exposure or elevated temperatures. These sheets are ideal for critical sealing, lining, and protection applications in the oil & gas, chemical, aerospace, pharmaceutical, and automotive industries.
APPLICATIONS
Where this product is used
FKM Rubber Sheets are designed for demanding industrial environments requiring superior chemical, heat, and oil resistance.
- Oil & Gas Industry
- Petrochemical Plants
- Chemical Processing Industries
- Refineries
- Aerospace Industry
- Automotive Industry
- Pharmaceutical Manufacturing
- Food Processing Equipment (Non-food contact applications unless FDA-compliant grade is specified)
- Power Generation Plants
- Industrial Gaskets and Seals
- O-Rings and Sealing Components
- Pump and Valve Seals
- Heat Exchangers
- Hydraulic Systems
- Compressor Equipment
- Marine and Offshore Applications
- Laboratory Equipment
- High-Temperature Industrial Machinery
KEY FEATURES
Performance characteristics
Our FKM Rubber Sheets are manufactured using premium-quality fluoroelastomer compounds to ensure exceptional performance, reliability, and long service life in the most demanding industrial applications.
- Outstanding resistance to high temperatures.
- Excellent resistance to mineral oils, fuels, diesel, petrol, lubricants, and greases.
- Superior resistance to aggressive chemicals, acids, alkalis, and solvents.
- Exceptional resistance to ozone, UV radiation, weathering, and oxidation.
- Excellent ageing characteristics for extended service life.
- High tensile strength with excellent tear resistance.
- Outstanding compression set resistance for reliable sealing.
- Excellent resistance to hydraulic fluids and many industrial media.
- Low gas permeability for enhanced sealing performance.
- Superior dimensional stability under extreme operating conditions.
- Easy to fabricate, cut, and install.
- Manufactured in accordance with international quality standards.
TECHNICAL SPECIFICATIONS
Technical specifications and available configurations
Values are based on the supplied product document and should be confirmed for the selected grade, dimensions and application.
Technical table 1
| Property | Specification |
|---|---|
| Material | Fluoroelastomer (FKM) |
| Hardness | Available in various Shore A grades |
| Thickness | 1 mm to 50 mm (Customisable) |
| Width | Available in standard and custom widths |
| Length | Available in rolls or cut sheets |
| Density | As per application requirements |
| Surface Finish | Smooth / Fabric Impression |
| Colour Options | Black, Brown, Green and Custom Colours |
| Reinforcement | Plain or Fabric Insert |
| Working Temperature | 20°C to +250°C (Special grades may withstand higher intermittent temperatures) |
FKM-01
| Property | Value |
|---|---|
| Polymer | FKM |
| Density | 1.98 +/-0.05 g/cm3 |
| Hardness | 75 +/-5 Shore A |
| Tensile Strength | ≥6 MPa |
| Elongation at Break | ≥200% |
| Working Temperature | 20 to 205°C |
| Color | Black |
FKM-02
| Property | Value |
|---|---|
| Polymer | FKM |
| Density | 1.99 +/-0.05 g/cm3 |
| Hardness | 75 +/-5 Shore A |
| Tensile Strength | ≥9 MPa |
| Elongation at Break | ≥250% |
| Working Temperature | 20 to 215°C |
| Color | Black |
FKM-03
| Property | Value |
|---|---|
| Polymer | FKM |
| Density | 2 +/-0.05 g/cm3 |
| Hardness | 90 +/-5 Shore A |
| Tensile Strength | ≥10 MPa |
| Elongation at Break | ≥100% |
| Working Temperature | 20 to 215°C |
| Color | Black |
FKM-04
| Property | Value |
|---|---|
| Polymer | FKM |
| Density | 1.85 +/-0.05 g/cm3 |
| Hardness | 55 +/-5 Shore A |
| Tensile Strength | ≥6 MPa |
| Elongation at Break | ≥500% |
| Working Temperature | 20 to 215°C |
| Color | Black |
ADVANTAGES
Practical benefits
- Exceptional resistance to extreme temperatures.
- Outstanding resistance to oils, fuels, chemicals, and solvents.
- Excellent sealing performance with low compression set.
- Superior durability in harsh industrial environments.
- Excellent resistance to ageing, ozone, and weather exposure.
- Long service life with reduced maintenance costs.
- Ideal for high-performance industrial sealing applications.
- Reliable performance in critical operating conditions.
INDUSTRIES SERVED
Relevant industrial sectors
Industry references below are taken from the supplied product content.
Oil & GasPetrochemicalChemical ProcessingAerospaceAutomotivePharmaceuticalPower GenerationMarine & OffshoreFood Processing EquipmentHeavy EngineeringManufacturingGeneral Industrial Applications
